100G QSFP28 LR4 20KM
100G QSFP28 LR4 20KM
100G QSFP28 LR4 20KM

Type: QSFP-100G-LR4 Optical Components:
Data Rate:
103.1 GbP
Output Power:
1296nm, 1300nm, 1305nm and 1309nm
Receiver Sensivity:
≤ -10.6dBm
Cable Type:
LC Temperature Range:
0 to 70°C

Share it:
  • Product Features
  • Applications
  • Downloads
  • T8PLHG20D-L is a transceiver module designed for 20km optical communication applications. The design is compliant to 100GbASE-LR4 of the IEEE 802.3-2012 Clause 88 standard IEEE 802.3bm CAUI-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard . The module converts 4 inputs channels (ch) of 25.78 Gbps to 27.95Gbps electrical data to 4 lanes optical signals, and multiplexes them into a single channel for 100Gb/s optical transmission. Reversely, on the receiver side, the module optically de-multiplexes a 100Gb/s input into 4 lanes signals, and converts them to 4 lanes output electrical data.

    The central wavelengths of the 4 lanes are 1296nm, 1300nm, 1305nm and 1309nm . It contains a duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. To minimize the optical dispersion in the long-haul system, single-mode fiber (SMF) has to be applied in this module.

  • Local Area Network (LAN)

    Wide Area Network (WAN)

    Ethernet switches and router applications
